Mercedes-Benz Antos 2540 Kraanwagen Hiab 144-4 Hiduo

Mercedes-Benz Antos 2540 6x2 + HIAB XS 144 E-4 HiDuo Loading Crane

Make: Mercedes-Benz
Model: Antos 2540
Type: 6x2 flatbed truck with loading crane
First registration: 06/03/2016
Mileage: 402,822 km
Emission standard: Euro 6 / BlueTec 6
Cab: Day cab
Steering: Left-hand drive

Engine & Drivetrain

Engine power: 290 kW / 394 hp
Fuel: Diesel
Emission standard: Euro 6
Transmission: Mercedes-Benz PowerShift automatic transmission
Drivetrain: 6x2
Rear axle: Steerable trailing axle
Power Take-Off (PTO): Present, for crane operation

Weights

Permissible total weight: 26,000 kg
Technically permissible total weight: 26,000 kg
Permissible front axle load: 8,000 kg
Permissible drive axle load: 12,000 kg
Permissible trailing axle load: 7,500 kg
Permissible total train weight: 40,000 kg

Flatbed body

Open flatbed body
High aluminum side walls
Side walls individually foldable
Foldable rear side wall
Level loading area
Integrated load securing rails in the loading area
Crane mounted directly behind the cab
Hydraulic outriggers
Tow hitch at the rear
Lateral underrun protection

HIAB Loading Crane

Manufacturer: HIAB
Type: XS 144 E-4 HiDuo
Crane type: Hydraulic knuckle boom loading crane
Crane class: approx. 14 mt
Hydraulic extensions: 4
Max. hydraulic reach: approx. 12.8 m
Max. lifting moment: approx. 138 kNm
Slew range: approx. 415°
Hydraulic outriggers: Yes
Load hook: Yes
Control: HIAB HiDuo
Remote control: Yes – radio remote control

Lifting capacities HIAB XS 144 E-4 HiDuo

At approx. 2.5 m: 5,200 kg
At approx. 4.7 m: 2,800 kg
At approx. 6.5 m: 1,940 kg
At approx. 8.4 m: 1,440 kg
At approx. 10.5 m: 1,100 kg
At approx. 12.8 m: 900 kg

Lifting capacities according to the load chart attached to the crane.

Equipment

Air conditioning
Cruise control
On-board computer
Digital tachograph
Electric windows
Hedpfx Acsz Hny Tjmou
Electrically adjustable exterior mirrors
Multi-function steering wheel
Radio
24V socket
Air-suspended driver's seat
Roof hatch
Differential lock
ABS
Euro 6 / BlueTec 6
Mercedes-Benz PowerShift automatic transmission
Power Take-Off (PTO)
HIAB loading crane
Radio remote control for the crane
Hydraulic outriggers
Steerable trailing axle
Tow hitch

Mercedes-Benz Antos 2540 6x2, built in 2016, with 402,822 km. Euro 6, Mercedes-Benz PowerShift automatic transmission, open flatbed body, and HIAB XS 144 E-4 HiDuo loading crane. The crane features 4 hydraulic extensions, a hydraulic reach of approx. 12.8 m, hydraulic outriggers, and radio remote control. Versatile and fully equipped vehicle for transport, loading, and lifting operations.

= Further information =

Front axle: Steered
Rear axle 1: Lift axle; Steered
Unladen weight: 13,890 kg
Payload: 12,110 kg
GVW: 26,000 kg
CE marking: yes
Technical condition: very good
Optical condition: very good
Price: On request
