Omac-Italy Hydraulische Winde-Bremse 5T F120.50.2

Hydraulic Winch Brake, 5 Tons, OMAC F120.50 (T50.2) – Puller-Tensioner, 50 kN for Overhead Line Construction, OPGW, and Cable Laying

For sale is a professional hydraulic winch brake, OMAC Italy F120.50 (T50.2), for overhead line construction, cable laying, network construction, catenary construction, and the installation of medium and high-voltage lines.

The machine is designed for tensioning, braking, and pulling one or two conductors as well as OPGW / fiber optic cables. Thanks to the hydraulic circuit, the winch brake can operate with constant force – both in braking mode and in winching mode. This makes the machine ideally suited for controlled operations during the construction, modernization, and maintenance of overhead lines and energy infrastructure.

The OMAC F120.50 is a robust solution for energy suppliers, network construction companies, overhead line construction companies, cable laying companies, railway technology companies, catenary construction companies, and specialized installation companies.

Technical data:

* Manufacturer: OMAC Italy
* Model: F120.50 (T50.2)
* Machine type: Hydraulic winch brake / puller-tensioner / cable winch
* Application: Overhead line construction, OPGW, cable laying, catenary construction
* Winches / drums: 2 × Ø 1500 mm
* Maximum conductor / cable diameter: 1 × 36 mm
* Max. braking force: 50 kN / approx. 5 tons
* Min. braking force: 2 kN
* Max. speed in braking mode: 5 km/h
* Max. pulling force in winching mode: 50 kN / approx. 5 tons
* Min. pulling force in winching mode: 2 kN
* Max. speed in winching mode: 0.8 km/h
Guedpfezdfdnsx Amxsc
* Weight: approx. 2500 kg
* Dimensions: approx. 395 × 200 × 240 cm

Equipment and advantages:

* Hydraulic winch brake for tensioning one or two conductors or OPGW
* Constant braking and pulling force even with varying working speeds
* Motor for retraction power
* Strain control device for low forces 2–20 kN, suitable for fiber optic / OPGW
* Load cell reading system
* Control panel with large color graphic display
* USB port for data storage
* Display of pulling force, speed, and cable length in real time
* Adjustment of the maximum pulling force
* Working time and data recording
* Safe hydraulic brake
* Rear cable guidance with nylon rollers
* Chassis with solid axle, handbrake, and detachable drawbar for slow towing on the construction site
* Mechanical front support and rear stabilizers
* Anchoring and lifting accessories
* Heat exchanger for oil cooling in the hydraulic circuit
* Additional hydraulic circuit for controlling 1 or 2 reel stands
* Grounding point

Options depending on configuration:

* Spring axle, air brake, drawbar, and lighting for road transport
* PVC protective cover
* Cable remote control 10 m
* Radio remote control up to approx. 50 m
* Automatic clamps for 2 conductors
* Manual clamp for 2 conductors
* Electronic recorder with accessories

The OMAC F120.50 hydraulic winch brake is ideal for professional users looking for a powerful 50 kN machine for overhead line construction, OPGW installation, cable pulling, cable laying, and energy infrastructure.

Technical advice, availability, and individual offers available upon request.

Intra-community delivery net without VAT is possible with a valid VAT ID.

Other versions available upon request.
